Eurobird 9A at 9.0°E

Eurobird 9A at 9.0°E : Technical data

eurobird 9a at 9.0 e _ wide footprint_snap 001

                     satellite: Eurobird 9A - orbit : 9.0°E - TP : 20 KU - lifetime : from 11.3.2006 - 15 years

Update-Eurobird 9A at 9.0°E-wide footprint : quality measurement and analysis of the income spectrum

              Eurobird 9A at 9.0°E - wide  footprint : measurements at the center Lučenec/central Slovakia
                                          geographical location :
Latitude: 48.33°  _   Longitude: 19.72°
                                       measurement results are derived from the 3.7 m diameter antenna
                                                                            Elevation angle : 33.3°

                               Eurobird 9A spectral analysis                      Eurobird 9A footprint_wide
                                TP 60>62>64>66 : SPAN 6            Europe,West Asia,Middle East,part of n. Africa
                        eurobird 9a at 9.0 e _ wide footprint_spectral analysis    eurobird 9a at 9.0 e _ wide footprint
                                                              - time of measurement : 17.1.2010 -
                                                                 - defining the status of income -

11 996 V - packet GlobeCast_MER=15.6 dB / NM=9.2 dB : It is a typical situation the quality of income that can be
measured at each carrier in the spectrum of wave V and H measurements in the zone of peak flow levels EIRP 50 dBW
>>> depending on the settings SKEW angle, which may vary depending on the selection of the transponder in the plane
 wave V and H .


                                            Eurobird 9A at 9.0°E - wide footprint : 11 727 V Packet Arqiva
                         IF data                                                        Q data                                                 NIT data
eurobird 9a at 9.0 e _ wide footprint_11 727 V Packet Arqiva_IF dataeurobird 9a at 9.0 e _ wide footprint_11 727 V Packet Arqiva_Q dataeurobird 9a at 9.0 e _ wide footprint_11 727 V Packet Arqiva_NIT data

                                           Eurobird 9A at 9.0°E - wide footprint : 11 804 V Unn. network
                         IF data                                                        Q data                                                 NIT data
eurobird 9a at 9.0 e _ wide footprint_11 804 V unn. network_IF dataeurobird 9a at 9.0 e _ wide footprint_11 804 V unn. network_Q dataeurobird 9a at 9.0 e _ wide footprint_11 804 V unn. network_NIT data

                                         Eurobird 9A at 9.0°E - wide footprint : 11 823 H Packet SkyLogic
                         IF data                                                        Q data                                                 NIT data
eurobird 9a at 9.0 e _ wide footprint_11 823 H SkyLogic _IF dataeurobird 9a at 9.0 e _ wide footprint_11 823 H SkyLogic _Q dataeurobird 9a at 9.0 e _ wide footprint_11 823 H SkyLogic _NIT data

                                       Eurobird 9A at 9.0°E - wide footprint : 11 958 V Packet m2 Mediatech
                         IF data                                                        Q data                                                 NIT data
eurobird 9a at 9.0 e _ wide footprint_11 958 V Packet M2_IF dataeurobird 9a at 9.0 e _ wide footprint_11 958 V Packet M2_Q dataeurobird 9a at 9.0 e _ wide footprint_11 958 V Packet M2_NIT data

                                         Eurobird 9A at 9.0°E - wide footprint : 11 996 V Packet GlobeCast
                         IF data                                                        Q data                                                 NIT data
eurobird 9a at 9.0 e _ wide footprint_11 996 V Packet GlobeCast_IF dataeurobird 9a at 9.0 e _ wide footprint_11 996 V Packet GlobeCast_Q dataeurobird 9a at 9.0 e _ wide footprint_11 996 V Packet GlobeCast_NIT data

                                      Eurobird 9A at 9.0°E - wide footprint : 12 015 H Packet KabelKiosk
                         IF data                                                        Q data                                                 NIT data
eurobird 9a at 9.0 e _ wide footprint_12 015 H Packet KabelKiosk _IF data  eurobird 9a at 9.0 e _ wide footprint_12 015 H Packet KabelKiosk _Q data eurobird 9a at 9.0 e _ wide footprint_12 015 H Packet KabelKiosk _NIT data

                                             Eurobird 9A at 9.0°E - wide footprint : 12 092 H Euro TSA
                         IF data                                                        Q data                                                 NIT data
eurobird 9a at 9.0 e _ wide footprint_12 092 H Packet TSA _IF dataeurobird 9a at 9.0 e _ wide footprint_12 092 H Packet TSA _Q dataeurobird 9a at 9.0 e _ wide footprint_12 092 H Packet TSA _NIT data

                                       Eurobird 9A at 9.0°E - wide footprint : 12 360 H Packet KabelKiosk
                         IF data                                                        Q data                                                 NIT data
eurobird 9a at 9.0 e _ wide footprint_12 360 H Packet KabelKiosk _IF dataeurobird 9a at 9.0 e _ wide footprint_12 360 H Packet KabelKiosk _Q dataeurobird 9a at 9.0 e _ wide footprint_12 360 H Packet KabelKiosk _NIT data

                                           Eurobird 9A at 9.0°E - wide footprint : 12 380 V Platforma HD
                         IF data                                                        Q data                                                 NIT data
eurobird 9a at 9.0 e _ wide footprint_12 378 V Platforme HD _IF dataeurobird 9a at 9.0 e _ wide footprint_12 378 V Platforme HD _Q dataeurobird 9a at 9.0 e _ wide footprint_12 378 V Platforme HD _NIT data


Eurobird 9A at 9.0°E : TV List

eurobird 9a at 9.0 e _ wide footprint_PF Prodelin 3.7m


---Frequency---


----------Provider/Channel----------

---SR--- ---FEC--- ---footprint--- ---Antenna--- ----DVB/Encryption----

11 727 -V-tp 50

Arqiva 27 500 3/4 wide 60-120+ cm DVB
  Mooby TV         FTA
  testcard Arqiva LA/EB 9 OU 1         FTA
  TNT Germany         Cryptoworks
  ESPN America UK         Cryptoworks
  ANN         FTA
  ESPN Classic         Cryptoworks
  ESPN America NASN         Cryptoworks
  Shorts TV France         FTA
  Disney Channel DCRB         Cryptoworks

11 747 -H-tp 51

Skylogic 27 500 3/4 wide 60-120+ cm DVB
  Link promo         FTA
  Dipré Art Channel         FTA
  Rete 7         FTA
  Italiani nel mondo         FTA
  Teleitalia TV promo         FTA
  3D Sat TV HD         MPEG-4/HDTV
  Sisal TV         X-Crypt

11 785 -H-tp 53

Kabel Kiosk 27 500 2/3 wide 60-120+ cm DVB-S2/8PSK
  Channel 21 Shop         Conax/Videoguard
  MTV Deutschland         Conax/Videoguard
  Nickelodeon/Comedy Central         Conax/Videoguard
  Viva         Conax/Videoguard
  TIMM         Conax/Videoguard
  HSE 24         Conax/Videoguard
  Russia Today English         Conax/Videoguard
  1-2-3 TV         Conax/Videoguard
  I-Music 1         Conax/Videoguard
  Yavido Clips         Conax/Videoguard
  CNN International Europe         Conax/Videoguard
  CNBC Germany         Conax/Videoguard
  Das Vierte         Conax/Videoguard

11 804 -V-tp 54

unn. network 27 500 3/4 wide 60-120+ cm  DVB
  LUXE.TV SD         FTA
  C-Music         FTA
  My Zen.tv         Viaccess 3.0
  My Zen.tv HD         MPEG-4/HD/Vcs 2.6+3.0/Conax
  LUXE.TV HD         MPEG-4/HD/FTA

11 823 -H-tp 55

Skylogic 27 500 3/4 wide 60-120+ cm DVB
  TVBS Europe         Irdeto 2
  TVBN         Irdeto 2
  TVB Entertainment news         Irdeto 2
  TVB Classic         Irdeto 2
  TVB Life Style         Irdeto 2
  TV 2000 S2K         Biss
  Trace TV Tropical         FTA
  CCTV 4 Europe         FTA
  Noello Sat         FTA
  Jewels Sorg 1         FTA
  Jewels Sorg 2         FTA
  Tivuitalia         FTA

11 843 -V-tp 56

unn. network 27 500 3/4 wide 60-120+ cm DVB
  Mesopotamia TV         FTA
  Roj TV         FTA
  Newroz TV         FTA
  Bluemoon TV         FTA
  Live Channel         FTA
  Zee TV UK         Irdeto 2
  test         FTA
  KNN Channel         FTA
  Zee TV Russia         Irdeto 2
  Zee Cinema UK         Irdeto 2
  Al Rasheed TV         FTA
  Finest TV         FTA
  Top TV         FTA

11 861 -H-tp 57

Kabel Kiosk 27 500 2/3 wide 60-120+ cm DVB-S2/8PSK
  RTL Deutschland         Conax/Videoguard
  RTL 2 Deutschland         Conax/Videoguard
  Super RTL         Conax/Videoguard
  VOX         Conax/Videoguard
  n-tv         Conax/Videoguard
  Pro 7         Conax/Videoguard
  Sat 1         Conax/Videoguard
  Kabel 1         Conax/Videoguard
  N24         Conax/Videoguard
  9Live         Conax/Videoguard

11 881 -V- tp 58

RRSat Global Network

27 500 2/3 wide 60-120+ cm DVB-S2/8PSK
  Fashion HD         MPEG-4/HD/FTA
  i-Concert         MPEG-4/HD/Viaccess 2.6
  HD 1 EURO 1080         MPEG-4/HD/Viaccess 2.6
  Bebe TV HD         MPEG-4/HD/Viaccess 2.6

11 900 -H- tp 59

Unn. network

27 500 3/4 wide 60-120 + cm DVB
  TSG / test card         MPEG-2/FTA
  TSG4 / test card         MPEG-4/FTA

11 918 -V-tp 60

RRSat Global Network 27 500 3/4 wide 60-120+ cm DVB
  Bom Deus
  Rainbow         FTA
  River network         FTA
  FOX Sports ME         MPEG-4/Viaccess 2.6
  SVT World         Viaccess 2.6
  TIN The Israeli network         Viaccess 2.6
  Pars TV         FTA
  Divine TV         FTA
  Al Alamia         FTA
  NLM         FTA
  Amrita TV channel         FTA
  MTA 3         FTA
  Angel TV         FTA
  Nepali TV         FTA
  Asianet         Viaccess 2.5+2.6
  Asianet plus         Viaccess 2.5+2.6
  The Karaoke Channel         Irdeto 2

11 938 -H-tp 61

GlobeCast 27 500 3/4 wide 60-120+ cm DVB
  TV Lanka Channel 2         Viaccess 2.5
  Walf TV         Viaccess 2.5
  Neth TV Sri Lanka         FTA
  Fantasy Channel         Biss
  Rai 3 Africa         Viaccess 2.5


11 958 -V-tp 62

Magyar TV 2

 27 500  3/4  wide 60-120+ cm DVB
  m2         FTA
  m2 16:9         FTA
  m2 HD         MPEG-4/HDTV

11 977 -H-tp 63

Media Broadcast 27 500 3/4 wide 60-120+ cm DVB
  Testbild Media Broadcast         DVB FTA
  OCC         PowerVu
  OCC 2         PowerVu
  Akubis Classic         PowerVu
  Akubis Direkt         PowerVu
  Akubis Special IG         PowerVu

11 996 -V-tp 64

Globecast 27 500 3/4 wide 60-120+ cm DVB
  MTV Portugal         Cryptowork
  BBC Entertainment Europe         Viaccess 3.0
  B4U Movies ME         FTA
  SUN TV MP2         FTA
  CCTV 4 Europe         FTA
  CCTV E         FTA
  CCTV Russkij         FTA
  CCTV Arabic         FTA
  SUN TV         MPEG-4/Irdeto 2
  SUN KTV         MPEG-4/Irdeto 2
  SUN Music         MPEG-4/Irdeto 2
  SUN Adithya TV         MPEG-4/Irdeto 2
  SUN Chutti TV         MPEG-4/Irdeto 2

12 015 -H-tp 65

Kabel Kiosk 27 500 2/3 wide 60-120+ cm DVB-S2/8PSK
  BBC World News         Conax/Videoguard
  Bloomberg         Conax/Videoguard
  TV 5 Monde         Conax/Videoguard
  Tele 5         Conax/Videoguard
  QVC         Conax/Videoguard
  DAF         Conax/Videoguard
  Luxe TV         Conax/Videoguard
  Deluxe Music TV         Conax/Videoguard
  TV Gusto         Conax/Videoguard
  DSF         Conax/Videoguard
  Volksmusik         Conax/Videoguard
  XX Home test         Conax/Videoguard
  uprom         Conax/Videoguard
  Bibel TV         Conax/Videoguard
  France 24 English         FTA

12 034 -V- tp 66

Hello HD 27 500 3/4 wide 60-120+ cm DVB-S2/8PSK/Conax
  m1 HD         MPEG-4/HD/Conax
  HBO Hungary HD         MPEG-4/HD/Conax
  Discovery HD         MPEG-4/HD/Conax
  TCM/Cartoon Network         MPEG-4/Conax
  HBO 2         MPEG-4/Conax
  HBO Comedy         MPEG-4/Conax
  Spektrum TV         MPEG-4/Conax
  Filmbox Extra         MPEG-4/Conax
  Hir TV         MPEG-4/Conax
  Eurosport 2         MPEG-4/Conax
  Discovery Hungary         MPEG-4/Conax
  MusicMix/MusicMix Adult /23-04/         MPEG-4/Conax
  Minimax/Animax         MPEG-4/Conax
  Viasat 3         MPEG-4/Conax
  MTV Hungary         MPEG-4/Conax
  Animal Planet Hungary         MPEG-4/Conax
  Viva TV         MPEG-4/Conax
  Comedy Central         MPEG-4/Conax
  National Geographic         MPEG-4/Conax
  National Geographic Wild         MPEG-4/Conax

12 054 -H-tp 67

Penthouse HD network

27 500 2/3 wide 60-120+ cm DVB-S2/8PSK
  Penthouse HD promo/test card         MPEG-4 /HDTV
  Penthouse HD         MPEG-4 /HDTV/DRE-Crypt
  Penthouse HD 1         MPEG-4 /HDTV/DRE-Crypt
  Penthouse HD 2         MPEG-4 /HDTV/DRE-Crypt

12 074 -V- tp 68

Hello HD 27 500 3/4 Europe 60-120+ cm DVB-S2/8PSK/Conax
  Filmbox HD         MPEG-4/HD/Conax
  National Geographic UK HD         MPEG-4/HD/Conax
  The History Channel UK HD         MPEG-4/HD/Conax
  Magyar ATV         MPEG-4/Conax
  TV 2         MPEG-4/Conax
  RTL Klub         MPEG-4/Conax
  Cinemax         MPEG-4/Conax
  AXN         MPEG-4/Conax
  4! Story TV         MPEG-4/Conax
  Sport 2 Hungary         MPEG-4/Conax
  Film+ Hungary         MPEG-4/Conax
  Sport Klub Hungary         MPEG-4/Conax
  Hallmark Channel         MPEG-4/Conax
  Sport 1 Hungary         MPEG-4/Conax
  Travel Channel         MPEG-4/Conax
  Digi Sport         MPEG-4/Conax

12 092 -H-tp 69

TSA 27 500 3/4 Europe 60-120+ cm DVB
  TVE Internacional Asia-Africa         FTA
  Disney Cinemagic Espaňa         Viaccess 2.6
  Disney Cinemagic Espaňa +1         Viaccess 2.6
  Action TV / OPAL TV         FTA
  TSA feeds         occasional service
  Tu Tele Local         FTA
  Iberalia TV         KeyFly
  TSA feeds aierta         occasional service
  Parlamento Canal         FTA
  Destino Galicia         FTA

12 130 -H- tp 71

KabelKiosk 27 500 3/4 Europe 60-120+ cm DVB
  Pink Plus         Conax/Videoguard
  EuroStar         Conax/Videoguard
  RTR Planeta         Conax/Videoguard
  EuroNews         Conax/Videoguard
  Body in Balance         Conax/Videoguard
  Channel 1 Russia         Conax/Videoguard
  Lig TV         Conax/Videoguard
  Kinowelt TV         Conax/Videoguard
  Animax         Conax/Videoguard
  France 24 English          FTA

12 207 -H- tp 75

Platforma DV

27 500 2/3 Europe 60-120+ cm DVB-S2/8PSK/DRE-Crypt
  TLK Rossiya         MPEG-4/DRE-Crypt
  NTV         MPEG-4/DRE-Crypt
  TLK Sport         MPEG-4/DRE-Crypt
  TLK Kultura         MPEG-4/DRE-Crypt
  Bibigon         MPEG-4/DRE-Crypt
  STS         MPEG-4/DRE-Crypt
  Peterburg 5 kanal         MPEG-4/DRE-Crypt
  TNT          MPEG-4/DRE-Crypt
  Vesti         MPEG-4/DRE-Crypt
  Kinopokaz         MPEG-4/DRE-Crypt
  Kanal Teleputeshestviya         MPEG-4/DRE-Crypt
  REN TV         MPEG-4/DRE-Crypt
  Muz TV         MPEG-4/DRE-Crypt
  365 dnei         MPEG-4/DRE-Crypt
  Komedia TV         MPEG-4/DRE-Crypt
  Kuchnya TV         MPEG-4/DRE-Crypt
  Auto plus         MPEG-4/DRE-Crypt
  Tonus TV         MPEG-4/DRE-Crypt
  Zoo TV         MPEG-4/DRE-Crypt
  test         MPEG-4/DRE-Crypt

12 245 -H- tp 77
BSS network  27 500  3/4  wide 60-120+ cm DVB FTA
  Finest TV         FTA
  TOP TV         FTA
  Newroz TV         FTA
  Pen TV         FTA
  ICC+         FTA
  Al Rasheed TV         FTA
  Zagros TV         FTA
  Live Channel         FTA
  ATV Int         FTA
  Kanal 4         FTA
  KNN         FTA
  Korek TV         FTA
  RTV         FTA
  Komala TV         FTA

12 284 -H- tp 79

KabelKiosk

27 500 2/3 wide 60-120+ cm DVB-S2/8PSK
  Juwelo TV         Conax/Videoguard
  Der Schmuckkanal         Conax/Videoguard
  Sonnenclar TV         Conax/Videoguard
  Astro TV         Conax/Videoguard
  Eurosport Deutschland         Conax/Videoguard
  EuroNews         Conax/Videoguard
  TVE Internacional         Conax/Videoguard
  The Poker Channel         Conax/Videoguard

12 303 -V- tp 80

Platforma HD 26 400 2/3 Europe 60-120+ cm DVB-S2/8PSK/MPEG-2
  Kanal Teleputeshestviya HD         DRE-Crypt/HD
  Kinopokaz HD 2         DRE-Crypt/HD
  HD Life         DRE-Crypt/HD
  Zhenskiy Mir HD         DRE-Crypt/HD

12 322 -H- tp 81

KabelKiosk 27 500 3/4 Europe 60-120+ cm DVB
  Show Turk         Conax/Videoguard
  NTV Avrupa         Conax/Videoguard
  Kanal 7         Conax/Videoguard
  Euro D         Conax/Videoguard
  ATV Avrupa         Conax/Videoguard
  Rai Uno         Conax/Videoguard
  Rai Due         Conax/Videoguard
  Rai Tre         Conax/Videoguard
  TV Polonia         Conax/Videoguard
  TRK Turk         Conax/Videoguard
  Turk max         Conax/Videoguard

12 360 -H-tp 83

KabelKiosk 27 500 3/4 Europe 60-120+ cm DVB
  info canal         FTA
  C Music TV         Conax/Videoguard
  Lust Pur TV /20-06/         Conax/Videoguard
  Hustler TV XXX /21-05/         Conax/Videoguard
  Yacht & Sailing         Conax/Videoguard
  Focus Gesundheit         Conax/Videoguard
  rush HD Europe         Conax/Videoguard
  Travel Channel Deutschland         Conax/Videoguard
  ITVN Europe         Conax/Videoguard
  Auto Motor und Sport         Conax/Videoguard
  TV Country         Conax/Videoguard
  Animal Planet         Conax/Videoguard

12 380 -V- tp 84

Platforma HD 26 400 2/3 Europe 60-120+ cm DVB-S2/8PSK/DRE-Crypt
  Platforma HD promo         MPEG-2/FTA
  Kinopokaz HD         MPEG-2/DRE-Crypt
  Eurosport HD         MPEG-2/DRE-Crypt
  NGC HD         MPEG-2/DRE-Crypt
  HD Life         MPEG-2/DRE-Crypt
  MTVN HD         MPEG-2/DRE-Crypt

12 399 -H- tp 85

KabelKiosk

27 500 3/4 Europe 60-120+ cm DVB
  13TH Street         Conax/Videoguard
  SciFi Deutschland         Conax/Videogurad
  National Geographic         Conax/Videoguard
  AXN         Conax/Videoguard
  Silverline         Conax/Videoguard
  Boomerang         Conax/Videoguard
  Motors TV Deutschland         Conax/Videoguard
  test         Conax/Videoguard
  The History Channel         Conax/Videoguard
  TNT Film         Conax/Videoguard
  Cartoon Network         Conax/Videoguard
  Biography Channel         Conax/Videoguard

12 437 -H- tp 87


KabelKiosk

27 500 3/4 Europe 60-120+ cm DVB
  Yourfamily entertainment         Conax/Videoguard
  Romance TV         Conax/Videoguard
  BBC Entertainment         Conax/Videoguard
  E! Entertainment         Conax/Videoguard
  sportdigital         Conax/Videoguard
  MTV Entertainment         Conax/Videoguard
  Gute Laune TV         Conax/Videoguard
  Discovery Channel Deutschland         Conax/Videoguard
  Nick Junior         Conax/Videoguard
  VH1 Classic Europe         Conax/Videoguard
  Volksmusik TV         Conax/Videoguard


Eurobird 9A at 9.0°E : relative quality

relative Q  01relative Q  02relative Q  03

Eurobird 9A at 9.0°E : video presentation

       go to video section :
  watch video

Eurobird 9A at 9.0°E : update prepare

                  dxsatcs logo
                         CZECH & SLOVAK DX SATELLITE CLUB
                             international professional portal

                             Roman Dávid - author & founder
                             mail :
roman.david@dxsatcs.com

Eurobird 9A at 9.0°E footprint : wide

                       eurobird 9a at 9.0 e _ wide footprint


Eurobird 9A at 9.0°E : snapshots

CCTV 4 07CCTV Russia 04France 24  06
LUXE TV HD  01LUXE TV HD  02LUXE TV HD  05
