Atlantic Bird 1 at 12,5°W

Atlantic Bird 1 at 12,5°W:Technické parametre

       AB 1 at 12,5w ku  00

V kmitočtovom spektre prevádzača tp B6 na f=11 179 MHz je možné identifikovať v norme DVB-S2/8PSK/MPEG-4 paket Overon, ktorý je dostupný k príjmu v celej stredoeurópskej zóne s diametrami anténnych reflektorov 60-80+ cm .

 Názov : Atlantic Bird 1 - Pozícia : 12,5°W - TP : 24 KU - Životnosť : od 28.8.2002 - 15 rokov

Update nr.1 : Atlantic Bird 1 at 12,5°W - European footprint : 11 387 H Packet Eutelsat RMB

- z kvalitatívneho hľadiska pri umiestnení RX systému v centrálnej zóne s hladinou EIRP toku 51 dBW identifikovaná QPSK/Q analýza vyjadruje typický akostné stav stabilne nulovej okamžitej chybovosti Ch BER na úrovni E-08 pred Vtt. pri stabilnej neoscilujúcej MER amplitúde so špičkou okolo levelu MER=16 dB čo vyjadruje čitý akostný rast resp.detekčný zisk zostavy na úrovni viac ako 8 dB .

         AB 1 at 12,5W ku  01
11 389 H Packet Eutelsat RMB Q analyza v MPEG 2 karte11 389 H Packet Eutelsat RMB stabina ziskova hladina s rastom viac ako 8 dB nad uzamknutim nosnej11 389 H Packet Eutelsat RMB NIT ID paketu

Update nr.2 - Atlantic Bird 1 at 12,5°W - European footprint : 12 546 H Packet TIM B1

a 12 546 H Packet TIM B1 Q analyza stavu v MPEG 2 karte12 546 H Packet TIM B1 stabilne vysoka hladina detekcneho zisku zostavy s PF 365 na urovni 7 az 8 dB12 546 H Packet TIM B1 NIT ID paketu

Atlantic Bird 1 at 12,5°W : TV LIST/PREHĽAD TV

             PF Prodelin 365 at 12.5wku




-Frequency-


----------Provider/Channel----------

---SR--- ---FEC--- ---Beam--- ---Antenna--- ---DVB/Encryption---

10 960 -H- tp B1


feeds Vsat V-19 / OVERON ... 5 632 3/4 Europe 100-240+ cm FTA/Biss/4:2:2

10 969 -H- tp B1

feeds E-298/ Mallorca ... 5 632 3/4 Europe 100-240+ cm FTA/Biss/4:2:2

10 973 -H- tp B1


feeds BBC PY UKI-110 ... 13 600 3/4 Europe 100-240+ cm FTA/Biss/4:2:2
10 987 -H- tp B1



feeds BBC 422 Ms ... 6 666 7/8 Europe 100-240+ cm FTA/Biss/4:2:2
11 015 -H- tp B1



feeds D312 / OVERON ... 5 632 3/4 Europe 100-240+ cm FTA/Biss/4:2:2
11 024 -H- tp B1



feeds D312 / OVERON ... 5 632 3/4 Europe 100-240+ cm FTA/Biss/4:2:2
11 041 -H- tp B3



feeds E342 OVERON ... 3 500 3/4 Europe 100-240+ cm FTA/Biss/4:2:2
11 043 -V- tp B4



feeds UKI 498 SDI PAT ... 6 138 7/8 Europe 100-240+ cm FTA/Biss/4:2:2
11 044 -H- tp B3

feeds OVERON ... 5 631 3/4 Europe 100-240+ cm FTA/Biss/4:2:2
11 052 -V- tp B4



feeds UKI 498 ... 6 138 7/8 Europe 100-240+ cm FTA/Biss/4:2:2
11 053 -H- tp B3



feeds OVERON ... 5 631 3/4 Europe 100-240+ cm FTA/Biss/4:2:2
11 066 -H- tp B3



feeds Barcelona / OVERON ... 4 500 3/4 Europe 100-240+ cm FTA/Biss/4:2:2
11 072 -H- tp B3



feeds A-25 E-62 / OVERON ... 4 500 3/4 Europe 100-240+ cm FTA/Biss/4:2:2
11 080 -V- tp B4



feeds BBC UKI 734 P1 ... 4 224 7/8 Europe 100-240+ cm FTA/Biss/4:2:2
11 086 -V- tp B4



feeds BBC UKI-777 P1 ... 4 224 7/8 Europe 100-240+ cm FTA/Biss/4:2:2
11 091 -H- tp B3



feeds Gambutisat 03 ... 3 300 3/4 Europe 100-240+ cm FTA/Biss/4:2:2
11 092 -V- tp B4



feeds UKI 827 NEWCA ... 4 224 7/8 Europe 100-240+ cm FTA/Biss/4:2:2
11 098 -V- tp B4



feeds BBC Baghdad ... 4 224 7/8 Europe 100-240+ cm FTA/Biss/4:2:2
11 100 -H- tp B3



Al Hayat/LIFE Channel 2 000 5/6 Europe 80-140+ cm FTA
11 132 -H- tp B5



BH-TV1 3 255 3/4 Europe 80-140+ cm FTA
11 136 -V- tp B6



Al Rasheed TV / unn. service 3 700 5/6 Europe 80-140+ cm FTA
11 138 -H- tp B5



feeds Service 1 / OVERON ... 2 893 3/4 Europe 100-240+ cm FTA/Biss/4:2:2
11 146 -H- tp B5



feeds Service 1 ... 11 000 5/6 Europe 100-240+ cm FTA/Biss/4:2:2
11 161 -H- tp B5



feeds Default / OVERON ... 3 333 3/4 Europe 100-240+ cm FTA/Biss/4:2:2
11 175 -H- tp B5



Telekom Srbija 15 190 3/4 Europe 80-140+ cm FTA
  SVET PLUS         FTA
  feeds ADVANTEC-AB1         FTA
  FOX TV Srbija         Biss
11 179 -V- tp B6



Overon 22 400 2/3 Europe 80-140+ cm DVB-S2/8PSK/FTA
  Canal 50         MPEG-4/FTA
  Nat Geo HD Russia & Turkey         MPEG-4/HD/Ird2/Mdg2
  Nat Geo Portugal         MPEG-4/Viaccess 2.5
  SET Portugal         MPEG-4/Viaccess 2.6
  Bainet Sat         MPEG-4/FTA
  Nat Geo Turqia         MPEG-4/Viaccess 2.5
  Animax Iberia         MPEG-4/FTA
  TLTV         MPEG-2/FTA
  AXN Portugal         MPEG-4/Viaccess 2.6
11 189 -H- tp B5



unnamed network 5 722 5/6 Europe 80-140+ cm DVB
  Nat Geo Germany         Biss
  Fox Germany         FTA
11 330 -H- Tp C7



feeds TJK MUSTI ... 3 214 5/6 Europe 100-240+ cm FTA/Biss/4:2:2
11 331 -H- tp C7



RR Sat Global 6 428 2/3 Europe 80-140+ cm DVB-S2/8PSK
  Exotica /22-04/         Biss
  Touch TV /22-3.30/         Biss
  Vip TV /22-3.30/         Biss
11 334 -H- tp C7



feeds TJK MURAT ... 3 214 5/6 Europe 100-240+ cm FTA/Biss/4:2:2
11 338 -H- tp C7



CCTV 4 1 923 7/8 Europe 80-140+ cm FTA
11 340 -H- tp C7



Cancao Nova TV Brazil 2 279 5/6 Europe 80-140+ cm FTA
11 355 -H- tp C7



RMB-AB1C07 11 781 7/8 Europe 80-140+ cm DVB
  Dorcel TV         Viaccess 2.6/3.0/Mdg2
  Bethel TV         FTA
  ACQ-KBN         FTA
  Speda promo         FTA
11 387 -H- tp C9



Eutelsat 27 500 7/8 Europe 80-140+ cm DVB
  Boomerang Germany         Viaccess 2.6
  Cartoon Germany         Viaccess 2.6
  TCM Germany         Viaccess 2.6
  ASQ-KBN         FTA
12 515 -H- tp F1



Telecom Italia 17 455 3/4 Europe 80-140+ cm  DVB
  La 7         FTA
  Dahlia Sport         Irdeto 2
  Dahlia Extreme         Irdeto 2
  Dahlia Eros         Irdeto 2
  Dahlia 4 Calcio         Irdeto 2
  Dahlia Adult         Irdeto 2
  Dahlia test         FTA
  Dahlia promo         FTA
12 536 -V- tp F2 unn. radio network

2 000 3/4 Europe 80-140+ cm FTA
12 545 -H- tp F1



Telecom Italia 17 455 3/4 Europe 80-140+ cm FTA
  Sportitalia         FTA
  Sportitalia 24         FTA
  LA7         FTA
  MTV Italia         FTA
  QOOB         FTA
  MediaShopping
12 584 -H- tp F3



feeds AGADIR ... 2 625 7/8 Europe 100-240+ cm FTA
12 594 -H- tp F3



Tiziana Sat 2 170 3/4 Europe 80-140+ cm FTA
12 597 -H- tp F3



Extra 3/first_service 1 730 3/4 Europe 80-140+ cm FTA
12 604 -H- tp F3



Calabria Channel/Pgm 1 1 481 3/4 Europe 80-140+ cm FTA
12 612 -H- tp F3



feeds ITA 494 ... 2 170 3/4 Europe 100-240+ cm FTA/Biss/4:2:2
12 655 -H- tp F5



Record International 4 285 3/4 Europe 80-140+ cm FTA
12 658 -V- tp F6



Zagros TV 2 604 5/6 Europe 80-140+ cm FTA
12 659 -H- tp F5



RIT 2 141 3/4 Europe 80-140+ cm FTA
12 662 -V- tp F6

Zagros TV 3 928 3/4 Europe 80-140+ cm FTA
12 670 -H- tp F5



feeds DVB Server ... 3 213 3/4 Europe 100-240+ cm FTA
12 708 -H- tp F7



Telecom Italia 18 000 3/4 Europe 80-140+ cm FTA
  La 7         FTA
  MTV Italia         FTA
  QOOB         FTA
12 715 -V- tp F8



left     Europe 80-140+ cm FTA
12 720 -V- tp F8



Puglia Channel 1 808 3/4 Europe 80-140+ cm FTA
12 743 -V- tp 8



Yacht & Sail/unn. service 3 214 3/4 Europe 80-140+ cm Viaccess 3.0



Atlantic Bird 1 at 12,5°W : Signal quality
Extra 3Sport Italiafeed Agadir

Atlantic Bird 1 at 12,5°W : Video presentation

-

Atlantic Bird 1 at 12,5°W footprint : European/North African/South American

AB 1 at 12,5W european beamAB 1 at 12,5W north american beamAB 1 at 12,5W south american beam

Atlantic Bird 1 at 12,5°W : TV Snapshots

FOX GermanyFOX GermanyLA 7
LA 7Liberty TV Liberty TV

Update nr.3 : Atlantic Bird 1 at 12,5°W - European footprint -DVB-S2/8PSK/MPEG-4 : 11 179 V Packet Overon

            AB 1 at 12,5W ku  02

-výrazné akostné rozpätie okolo 9 dB nad hladinou uzamknutia tejto v modulácii 8PSK vysielanej nosnej so stabilnou hladinou Q amplitúdy okolo levelu MER=14,5 dB .
11 179 V DVB-S2 Packet Overon z DVB Humax HDCI 200011 179 V DVB-S2 Packet Overon spektralna analyza paketu11 179 V DVB-S2 Packet Overon vysoka akost detekcie s okamzitou ziskovou rezervou viac ako 9 dB
11 179 V DVB-S2 Packet Overon pomerne vyjadrenie akosti z DVB Humax HDCI 200011 179 V DVB-S2 Packet Overon obsadenie v NIT ID z DVB Humax HDCI 200011 179 V DVB-S2 Packet Overon VA pids data Canal 50 z DVB Humax HDCI 2000

--- video all
---

11 179 V - DVB-S2/8PSK/MPEG-4 Packet Overon : TV SNAPSHOTS
DVB-S2 National Geographic Portugal 00DVB-S2 National Geographic Portugal 00DVB-S2 National Geographic Portugal
