Measat 3 at 91.5°E : Reliance Digital TV & technical parameters of satellite
.
Measat 3 : before launch Measat 3 : launch Measat 3 : satellite
___ Courtesy of MEASAT Satellite Systems ___
- Name : Measat 3
- Orbital position : 91.5°E
- Launched : 11.12.2006_23:28 UT / Bajkonur
- Launch vehicle : Proton-M/Briz-M
- Manufacturer/Provider : Boeing Satellite and Intelligence Systems, Inc / Measat Satellite Systems Malaysia
- Transponders in KU band : 24 (13.75-14.50/10.95-12.75 GHz, BW=24×36 MHz )
- Transponders in C band : 24 ( 5.925-6.725_3.400-4.200 GHz,BW=24×36 MHz )
- Geographic Coverage : South Asia , Malaysia and Indonesia
- Channel Polarization : linear
- Beacon Signals : C band 4 198 MHz / 4 199 MHz
- ULPC Beacon signal : KU 12 201 MHz V+H
.
Measat 3 at 91.5°E : Reliance Digital TV & point measurements and research
Measat 3 at 91.5°E : Reliance Digital TV & installed HF system
Measat 3 at 91.5°E : Reliance Digital TV & value of the elevation angle
.
- green_EL>=0°,red_EL<0°- theoretical possibility of receiving satellite in terms of elevation angle -
click for enlarge
.
Measat 3 at 91.5°E : Reliance Digital TV & South Asia Beam
.
--- theoretical footprint ---
